Třípásmová lineární zářivka T5 LT 49W T5-HQ/840 NBB

Product evaluation Favourite Comparison Send to email Whole product group The catalog


LT 49W T5-HQ/840 NBB
Order number: 105149840
Brand: NBB
Type / Description: Třípásmová lineární zářivka T5
Unit EAN13 code: 8595209950598
Guarantee: 24 months

Product is In stock

Watchdog
Insertion notification

Your price with VAT 146,65 Kč
Pcs

You are a corporate buyer? We have for you better prices! Sign up or Log in.


EXTREMELY POWERFULL system NARVA COLOURLUX T5 HQ                                                             HQ means HIGH OUTPUT. These lamps are characterized by high luminous flux. Therefore, it can be used in the new modern lighting applications or where high light intensity plays an important role. These lamps have the highest light output at 35°C. HQ fluorescent lamps are designed to operate only with electronic ballast and can be ideally used in system with motion sensors or dimmers and DALI systems just like all fluorescent lamps CLOURLUX NARVA and control their performance in dependence on the daylight and optimally affect electricity consumption. Fluorescent lamps LT-T5 series COLOURLUX  plus have very good colour rendering (Ra> 82). Therefore, they are very suitable for lighting of the workplace but also they have also use in industry, workshops, shops, public services, offices and in private areas. The tubes are available in different tones of white.

Exclusion of liability

Changes to data are subject to prior notice. NBB Bohemia s.r.o. accepts no responsibility for damages caused by inaccurate interpretation of the content on this site.

Warning

If broken in a closed room, we recommend ventilation to reduce the mercury vapor concentration. Use protective equipment while working. Immediately remove the shards so that they do not get injured. After removing the shards, use the technical means for decontamination of mercury. For this purpose we supply decontamination kits, which you can order by phone or in our internet shop. The decontamination kit should not be missed especially in plants where there is a danger of breaking light sources containing mercury, such as stores, warehouses, but can also be used in households. In case of nausea, give first aid and call a physician.

Notice

Fluorescent tubes of all types require a corresponding type of ballast to operate. A suitable ballast type can be found in the detail of the item (additional products). The quality and type of the ballast greatly affect the life of the fluorescent lamp. NBB Bohemia is not responsible for shortening lamp life when the fluorescent lamp is connected to a ballast type that NBB Bohemia s.r.o. because in such a case we can not guarantee the suitability of using the ballast to the supplied fluorescent tube. When directly connected to the mains voltage without using the ballast, the fluorescent lamp will be destroyed. Fluorescent tubes are not suitable for connection to motion sensors or for connection to frequent switching devices. Frequent switching causes shortening of lamp life. Frequent switching is considered to switch the fluorescent lamp to an interval of less than 20 minutes.

More photos available


Prices

without VAT VAT rate with VAT
Your price 1 Pcs 121,20 Kč 21% 146,65 Kč

Invertory

Stock code Stock Number
001 Centrála Benešov > 1000 Pcs

General information

Model/Description Zářivková trubice
Finish Lineární
Brand/Manufacturer NBB
Lamp type Zářivka
Nominal service life (h) 20000 h
Socket G5
Dimmable Ne
Lamp voltage (V) 195 V
Energy efficiency class (canceled regulation!) A
Dimmable by conventional dimmers Ne
Název položky LT 49W T5-HQ/840 NBB
Třída energetické účinnosti podle 2019/2015 G

Working conditions

Ambiente temperature for max. luminous flux 35 °C
Burning position Libovolná
Application Pro všeobecné osvětlování
Maximální počet sepnutí 100000 min

EuP Parameters

Average Lifetime B50 (h) 20000 h
Luminescence Life maintenance factor 46,9 %
Number of maximal switching cycles >100.000 /warm start
The rate of premature failures <1 %
Rated service life 20000 h
Energy consumption (AGGR) 49 kWh/1000h

Safety information

Safety instructions www.nbb.cz

Energetic characteristics

Rated efficiency after 100h 99,99 %
Lamp efficacy 80,0 lm/W

Lamp lumen maintenance factor (LLMF)

LLMF after 2.000 hrs 91,1 %
LLMF after 4.000 hrs 87,4 %
LLMF after 6.000 hrs 83,7 %
LLMF after 8.000 hrs 80,1 %
LLMF after 12.000 hrs 75,4 %
LLMF after 16.000 hrs 63,9 %
LLMF after 20.000 hrs 46,9 %

Electrical characteristics

Nominal wattage 49 W
Rated power (W) 49,0 W
Operating voltage (V) 195 V
Type of Voltage AC
Lamp operating current 0,251 A
Direct connection to the mains Ne
Lamp power 49 W
Voltage type AC
Total power (W) (light fitting) 49 W

Physical characteristics

Dimensions (mm) 16 x1449 mm
Packing method 20 - 1
Weight gross 165 g
Weight netto 140 g
Tube diameter 16 mm
Lamp shape T5
Length 1449 mm

Lighting characteristics

Type of spectrum Třípásmové
Color rendering 1B
Light Colour Chladná bílá
Wavelength range 400 - 800 nm
Dominant wavelength 544 nm
Luminous flux 4810 lm
Colour temperature 4000 K
Colour rendering index CRI 80 Ra
Colour of light 840
Beam angle Degrees (°) 360 °
Chromaticity coordinates x 0,384
Chromaticity coordinates y 0,382

Environmental characteristics

Mercury content 5,00 mg

Lamp surival factor (LSF)

LSF after 2.000 hrs 100,0 %
LSF after 4.000 hrs 100,0 %
LSF after 6.000 hrs 100,0 %
LSF after 8.000 hrs 100,0 %
LSF after 12.000 hrs 89,0 %
LSF after 16.000 hrs 84,0 %
LSF after 20.000 hrs 62,0 %


Download

Technical sheet

Technical sheet LT 49W T5-HQ/840 NBB

Download

Informační list

107.43 kB

Download

Energy label

41.87 kB
